The Bugatti Trust Photo Archive
Welcome to the Bugatti Trust Photo Gallery. The Trust has a collection of 25 large albums full of contemporary copy photographs. Click the link below for information on how to purchase our photographs
http://www.bugatti-trust.co.uk/the-bugatti-trust-photograph-archive/
178 Type 44
Engine from the exhaust side clearly showing the water pump with oil filler/filter above and oil pump below. Photo No: 178 Negative No: D1097_17 Type: 44 Album: 13
179. Type 44
Car prepared for exhibition purposes. Engine from the exhaust side clearly showing the water pump with oil filler/filter above and bulkhead mounted oil tank. Note hand scrapping on cambox and crankcase together with engine turned bulkhead. Photo No: 179 Negative No: D1097_23 Type: 44 Album: 13
180. Type 44
Engine front three quarter view exhaust side showing the front mounted crankshaft driven dynamo, exhaust manifolds, water pump with oil filler/filter above and oil pump below. Photo No: 180 Negative No: D1097_16 Type: 44 Album: 13
181. Type 44
Engine induction side clearly showing the distributor, bulkhead mounted ignition coil, inlet manifold and steering box. Photo No: 181 Negative No: D1097_22, 3_595_3 Type: 44 Album: 13
182. Type 44
Engine from the induction side clearly showing the carburettor and steering box. Photo No: 182 Negative No: D1097_21 Type: 44 Album: 13
183. Type 44
Engine from the exhaust side clearly showing the water pump with oil filler/filter above sandwiched between the exhaust manifolds. Photo No: 183 Negative No: 6_318_4 Type: 44 Album: 13
184. Type 44, Chassis # 44415, Reg. WE 2596
July 1994. Engine induction side clearly showing the distributor, bulkhead mounted ignition coil, inlet manifold, carburettor and steering box. Note non standard SU electric fuel pump. Photo No: 184 Negative No: 3_651_12 Type: 44 Reg: WE 2596 Date: July 1994 Album: 13
185. Type 44
Engine induction side clearly showing the carburettor modifications and Scintilla vertex magneto. Photo No: 185 Negative No: D1242_16 Type: 44 Album: 13
186. Type 44, Chassis # 441021
Lew Gotthainer, USA 1976. 1st to Enduardo de Matarazzio, Sau Paulo 29 June 1929. Orig eng no 725. Lionel & Mary Rogers (June 2003). Completed May 2007. Photo No: 186 Negative No: D1270_6 Type: 44 Chassis No: 441021 Engine No: 725 Location: USA Date: 1976 Album: 13
190. Type 44
Engine front three quarter view induction side showing the front mounted crankshaft driven dynamo, inlet manifold and carburettor. Note the steering box, drop arm and drag link running forward to the steering arm. Photo No: 190 Negative No: D1034_13, 6_318_6. Type: 44 Album: 13
191. Type 44
View forwards to the toeboard clearly showing the handbrake and gearlever, foot pedals, brake cross-shaft, clutch and flywheel. Photo No: 191 Negative No: 6_122_4 Type: 44 Album: 13
192. Type 44
olling chassis. View from the driving seat clearly showing the dashboard layout and controls. hoto No: 192 Negative No: D1097_25 Type: 44 Album: 13
193. Type 44
Front view with prominent crankshaft driven dynamo in cutout bottom centre of radiator. hoto No: 193 Negative No: D1034_11 Type: 44 Album: 13
194. Type 44
Brake cross-shaft partially obscuring the clutch mechanism and flywheel Photo No: 194 Negative No: 6_337_2 Type: 44 Album: 13
195. Type 44
Dashboard with central oval instrument cluster. Photo No: 195 Negative No: D1097_24 Type: 44 Album: 13
196. Type 44
Rolling chassis. View from the driving seat clearly showing the dashboard layout and controls. Photo No: 196 Negative No: 6_147_7 Type: 44 Album: 13
246. Type 44, Chassis # 44266
BOC Lewes c. 1935. Type 44 cut 'n' shut chassis, Kenneth W. Bear. Ref Bugantics vol.5 No. 4. Photo No: 246 Negative No: D1174_13 Type: 44 Chassis No: 44266 People: Kenneth W. Bear Location: Lewes Date: c. 1935 Album: 13
